Acoustic Door
Our organization offers a wide range of Acoustic Door that obstructs and prevents sound reverberations, which create superior sound with minimal energy-wave leakage. These are also known as acoustique doors which are a superb combination of superior passive acoustic damping techniques. These have electro magnetic lock for access controls and interlocking.
Our acoustic door sets, windows, walls and ceilings provide sound privacy in office, commercial and industrial environments.Our dorplus range of Acoustic doorsets, acoustic doors, soundproofed doors designed to give superior sound control and suitable for use in schools, studios and offices.
Purpose of door This is a door mechanism that obstructs and prevents sound reverberations creating superior quality of sound performance with minimal energy-wave leakage. Combination of superior passive acoustic damping techniques are used for excellent ensue.
IDEAL FOR Broadcasting, Post Production and Recording Studios
Language Laboratories
Cinemas
Theatres
Plant Rooms
Conference/Function Rooms
Kitchens
Offices
Audiometric Rooms
Machinery Enclosures
Features
45mm general purpose full flush design, rated for light to extra heavy-duty use
Kraft Honeycomb core provides structural strength and
exceptional flatness
Full-coat internal contact adhesive for permanent pressure
bond and rust prevention
Mechanically interlocked vertical edges for added strength and rigidity
Electro statically applied prime base coat / PU painted
Factory made insulated glazing
Standard Specifications
1.2mm thick, Galvanized Iron/ SS304 Hairline finish, 100x75 mm Single Rebated Frame / 150x75 Double Rebated Frames
0.8mm thick, Galvanized Iron / SS304 Hairline finish, 45mm thick
Shutters Seamless Design by application of epoxy filler or continuous welding (2mm thick shutters only)
4mm thick steel Back up plates for accessories mounting
Color as per RAL standard
Options
Glazing – Single or Double Glazed
Glass Size: 300x300; 300x600; 450x600; 450x900 (mm ); Special on request
Color finish –Matt or Glossy
Electro Magnetic Lock for Access Controls, Interlocking.
Accessories : Standard
Sound absorbent Seal
Quilt acrylic fibre covering
Hinges- SS 304
Pivots – Aluminum Die Casted
Locks – Concealed with SS 304 Sash Bar & 70mm Euro Profile Cylinder both side keys.
